22 Gauge 2/3/4/6 Conductor Teflon Shielded Cable 100FT Silver Plated Copper Shielded Wire 24 AWG FEP Insulated 600V 200°C High Temperature Wiring with Double EMI Shielding(3c-26A)

Technical Specifications:Conductor Material: Silver-plated copperInsulation Material: Transparent FEP Shielding: Aluminum foil + silver-plated copper braidTemperature Rating: -55°C to +200°CVoltage Rating: 600VLength: 32ft2 x 0.15mm² (26 AWG) - 7/0.16TS, OD: 2.8mm2 x 0.2mm² (24 AWG) - 7/0.20TS, OD: 3.2mm2 x 0.35mm² (22 AWG) - 19/0.16TS, OD: 3.7mm2 x 0.5mm² (20 AWG) - 19/0.18TS, OD: 3.9mm3 x 0.15mm² (26 AWG) - 7/0.16TS, OD: 3.0mm3 x 0.2mm² (24 AWG) - 7/0.20TS, OD: 3.4mm3 x 0.35mm² (22 AWG) - 19/0.16TS, OD: 3.9mm3 x 0.5mm² (20 AWG) - 19/0.18TS, OD: 4.1mm4 x 0.15mm² (26 AWG) - 7/0.16TS , OD: 3.2mm4 x 0.2mm² (24 AWG) - 7/0.20TS OD: 3.6mm4 x 0.35mm² (22 AWG) - 19/0.16TS, OD: 4.2mm4 x 0.5mm² (20 AWG) - 19/0.18TS, OD: 4.4mm6 x 0.15mm² (26 AWG) - 7/0.16TS, OD: 3.9mm6 x 0.2mm² (24 AWG) - 7/0.20TS, OD: 4.3mmKey Benefits:*Double Shielded Construction*High Temperature Rating: Rated -55°C to +200°C. *Silver Plated Conductors: Lower resistance, oxidation-resistant, easy soldering, stable at high frequencies.*Transparent Insulation: FEP jacket allows visual inspection of conductors and shielding.Typical Applications: Sensors Instrumentation Medical devices Robotics Power supplies Automotive Renewable energy High-temperature wiringNote: Professional installation recommended. Verify specifications meet your requirements before ordering.

• 【Double Layer Shielding for Signal Integrity】 Features dual-layer shielding construction with aluminum foil shield and silver-plated copper braid. This provides effective protection against electromagnetic interference, ensuring stable signal transmission and reduced signal loss in sensitive electronic applications
• 【High Temperature FEP Insulation Rated 200°C】 Insulated with transparent FEP (fluorinated ethylene propylene) material rated for continuous operation up to 200°C . The FEP insulation offers excellent flame retardance, chemical resistance, and dielectric strength for demanding environments
• 【Silver Plated Copper Conductors for Low Resistance】 Conductors are constructed from stranded silver-plated copper wire. Silver plating provides lower resistance than bare copper, improved oxidation resistance, and easier soldering for reliable terminations
• 【600V Voltage Rating with Low Eccentricity】 Rated for 600V applications with precision manufacturing ensuring low insulation eccentricity. This reduces risk of voltage breakdown and provides consistent electrical performance along the entire cable length
• 【Flexible and Durable Construction】 The FEP insulation and stranded conductor design provide good flexibility for installation in tight spaces. The material resists oils, while maintaining flexibility across wide temperature ranges
• 【Wide application range】Suitable for high-temperature wiring under 600V AC: instruments, sensors, motors, petrochemical equipment, power plants, HVAC controls, laboratory electronics, and more
